D001 FRONT/DASHBOARD EARTH

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	NZ		See K175 DRIVER'S SIDE FRONT AIR BAG SENSOR	1
2	5	A		See K175 DRIVER'S SIDE FRONT AIR BAG SENSOR	2

Wiring	Colour
See 20 DASHBOARD	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	NZ		See C050A AIR BAG EARTH (FACIA)	6
2	0,5	A		See M060A AIR BAG CONTROL UNIT (FACIA)	4
