Horns - wiring diagram

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Electrically activated devices › Horns - wiring diagram

Wiring diagrams and electrical functionsHorns - wiring diagram

HORNS - WIRING DIAGRAM

1.8 T.SPARK, 2.0 JTS, 1.9 JTD 16V

Wiring diagram

Components

Component code	Name	Assembly reference
B1	JUNCTION UNIT	Op. 1080B EXHAUST EMISSION CONTROL SYSTEM
B1	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B99	MAXIFUSE BOX ON BATTERY	Op. 5530B BATTERY AND LEADS
C11	RIGHT FRONT EARTH ( FRONT )
C15	FACIA EARTH, DRIVER''S SIDE
D1	FRONT DASHBOARD COUPLING ( FRONT )
D47	CLOCK SPRING ON STEERING WHEEL	Op. 5580C AIR BAG SYSTEM
H5	STEERING COLUMN SWITCH UNIT	Op. 5550A STALK UNIT
P10	HIGH-TONE HORN	Op. 5550B HORNS
P11	LOW-TONE HORN	Op. 5550B HORNS

3.2 V6

Wiring diagram

Components

Component code	Name	Assembly reference
B1	JUNCTION UNIT	Op. 1080B EXHAUST EMISSION CONTROL SYSTEM
B1	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B99	MAXIFUSE BOX ON BATTERY	Op. 5530B BATTERY AND LEADS
C11	RIGHT FRONT EARTH ( FRONT )
C15	FACIA EARTH, DRIVER''S SIDE
D1	FRONT DASHBOARD COUPLING ( FRONT )
D47	CLOCK SPRING ON STEERING WHEEL	Op. 5580C AIR BAG SYSTEM
H5	STEERING COLUMN SWITCH UNIT	Op. 5550A STALK UNIT
P10	HIGH-TONE HORN	Op. 5550B HORNS
P11	LOW-TONE HORN	Op. 5550B HORNS

19 Electrical
