D47 Clock spring coupling

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Intermediate couplings › D47 Clock spring coupling

Connectors and pin-outsD47 Clock spring coupling

D47 Clock spring coupling

Wiring	Colour
20 FACIA	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		HB		M60A	24
2		CB		M60A	23

Radio controls on steering wheel

Wiring	Colour
20 FACIA	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		D1	3
2		NZ		D97D	9
3		SV		P20C	11
4		SZ		P20C	10
5		LN		B2H	12
6		GH		C15A	8
7		NR		D1	7
8		HR		D1	8
11		MB		M60A	24
12		ZB		M60A	23
