C10 Front left earth

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Earths › C10 Front left earth

Connectors and pin-outsC10 Front left earth

C10 Front left earth

Wiring	Colour
12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NV		P90	3
2		NZ		O50	2
3		NZ		K25	2
4		NZ		F10	2
5	2,5	N		F10	1
6	2,5	N		N15	4
7		NZ		O51	2
8		NZ		K64	2
9		NZ		F20	2
10		NZ		F21	2
11		N		I31	4
12		N		K31	2
15	2,5	N		H5	7

1.8 T.SPARK, 2.0 JTS · Smart gearbox

Wiring	Colour
12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NV		P90	3
2		NZ		O50	2
3		NZ		K25	2
4		NZ		F10	2
5	2,5	N		F10	1
6	2,5	N		N15	4
7		NZ		O51	2
8		NZ		K64	2
9		NZ		F20	2
10		NZ		F21	2
11		N		I31	4
13		N		H37	2
14		N		H39	3
15	2,5	N		H5	7
16	2,5	N		N47

Xenon Gas headlamps

Wiring	Colour
12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NV		P90	3
2		NZ		O50	2
3		NZ		K25	2
6	2,5	N		N15	4
7		NZ		O51	2
8		NZ		K64	2
9		NZ		F20	2
10		NZ		F21	2
11		N		I31	4
12		N		K31	2
14	1	NZ		F10	5
15	2,5	N		H5	7
17	1,5	NV		F10	14
