Alfa Romeo GT Factory Service Manual (2003-2010)21 · Connectors and pin-outs

21 · General

H39 City switch

Make: Alfa Romeo
Model: GT Factory Service Manual
Year: 2003–2010
Section: Manual electric controls › H39 City switch

‹ Prev H37 Gear controls Next › H44 Electric window controls on front door

Connectors and pin-outsH39 City switch

H39 City switch

1.8 T.SPARK, 2.0 JTS · Smart gearbox

H39 City switch

Wiring	Colour
Connectors	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		HV		M54B	77
2		HR	X	B2A	13
				H37B	1
3		N		C10	14
