H37 Gear controls

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Manual electric controls › H37 Gear controls

Connectors and pin-outsH37 Gear controls

H37 Gear controls

H37A – Front

1.8 T.SPARK, 2.0 JTS · Smart gearbox

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ	X	M54B	65
				D1	7
2		GH		M54A	26
3		GN		M54B	68
4		BR		M54B	67
5		BV		M54B	74

H37B – Front

1.8 T.SPARK, 2.0 JTS · Smart gearbox

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		HR	X	B2A	13
				H39	2
2		NZ		C10	13
