ELECTRICAL

04

GENERAL SPECIFICATION DATA

8

INFORMATION

AIR CONDITIONING

System

CFC free, expansion valve system

.............................................................................

Compressor

Nippon Denso

.....................................................................

Refrigerant

R134a CFC free

.......................................................................

Charge quantity

750 g

±

50 g

................................................................

Refrigerant oil

ND-OIL 8

...................................................................

WIPER MOTORS

Tailgate wiper motor

Make/type

IMOS (non-serviceable)

........................................................................

Running current, wet screen at 20

°

C ambient

1.0 to 2.8 amps

.................

Wiper speed, wet screen at 20

°

C ambient

37 to 43 cycles per minute

.......................

Windscreen wiper motor

Make/type

Lucas 14W uprated two speed

........................................................................

Armature end float

0,1 to 0,2 mm

............................................................

Brush length, minimum

4,8 mm

....................................................

Brush spring tension

140 to 200 g

........................................................

Resistance of armature winding
at 16˚C (69˚F) measured between adjacent
commutatator segments

0.23 to 0.35 ohms

...................................................

Light running, rack disconnected: current at 13.5 V

2.0 amps

.........

Wiper speed, wet screen, 60 seconds from cold

Low speed - 45

±

3 rev/min, High speed - 65

±

5

..............

rev/min

ELECTRICAL

System

12 volt, negative ground

.............................................................................

Battery

Make/type

Delphi GP31

........................................................................

Alternator

Type

Nippon Denso

.................................................................................

Fuses

Type

Autofuse (blade type) blow ratings to suit individual

.................................................................................

circuits

Horns

Make/type

Mixo TR99

........................................................................

Starter motor

Make and type

Bosch 12v

.................................................................
