MANIFOLD COMPONENT LAYOUT
- Make
- Land Rover
- Model
- Defender TD5 Defender
- Section
- MANIFOLD COMPONENT LAYOUT
MANIFOLD AND EXHAUST SYSTEMMANIFOLD COMPONENT LAYOUT
MANIFOLD AND EXHAUST SYSTEM
1
DESCRIPTION AND OPERATION
MANIFOLD COMPONENT LAYOUT
1. Inlet manifold
2. Flanged nut - 2 off
3. Stud - 2 off
4. Stud - 10 off
5. Exhaust gasket
6. Flanged nut - 10 off
7. Exhaust manifold
8. Inlet gasket
9. Flanged bolt - 8 off
