BRAKES

GENERAL SPECIFICATION DATA

7

INFORMATION

SHOCK ABSORBERS

Type

Telescopic, double-acting non-adjustable

.................................................................................

Bore diameter

35.47mm

...................................................................

BRAKES

Front brake

Caliper

AP Lockheed, four opposed pistons

..............................................................................

Operation

Hydraulic, self adjusting

.........................................................................

Disc

90 - Solid, outboard, 110/130 - Ventilated, outboard

..................................................................................

Disc diameter

298 mm (11.73 in)

...................................................................

Disc thickness

90 - 14,1 mm (0.56in), 110/130 - 24mm (0.95 in)

..................................................................

Wear limit

1 mm (0.04in) per side of disc

.........................................................................

Disc run-out maximum

0,15mm (0.006 in)

.....................................................

Pad area

58 cm

2

(9.0 in

2

)

..........................................................................

Total swept area

801,3 cm

2

(124.2 in

2

)

...............................................................

Pad material

Ferodo 3440 non asbestos

.....................................................................

Pad minimum thickness

3 mm (0.12in)

...................................................

Rear brake

Caliper

AP Lockheed opposed piston

..............................................................................

Operation

Hydraulic, self adjusting

.........................................................................

Disc

Solid, outboard

..................................................................................

Disc diameter

90 - 290 mm (11.42 in), 110/130 - 298 mm (11.73)

...................................................................

Disc thickness

90 - 12,5 mm (0.49 in), 110/130 - 14,1 mm (0.56 in)

..................................................................

Wear limit

90 - 0,38 mm (0.015 in), 110/130 - 1,0 mm (0.04 in)

.........................................................................

per side of disc

Disc run-out maximum

0,15 mm (0.006 in)

.....................................................

Pad area

90 - 30,5 cm

2

(4.37 in

2

), 110/130 - 36,2 cm

2

(5.61 in

2

)

..........................................................................

Total swept area

90 - 694 cm

2

(106.98 in

2

)

...............................................................

Pad material

Ferodo 3440 non asbestos

.....................................................................

Pad minimum thickness

UP TO 02MY - 3 mm (0.12 in)

...................................................

Pad minimum thickness

From 02MY - 2 mm (0.08 in)

...................................................

Parking brake

Type

Mechanical, cable operated drum brake on the rear of

.................................................................................

the transfer gearbox output shaft

Drum internal diameter

254 mm (10.0 in)

.....................................................

Width

70 mm (2.75 in)

................................................................................

Pad material

Ferodo 3611 non asbestos

.....................................................................

Servo/master cylinder

Manufacturer

Lucas

....................................................................

Servo type

LSC 80

........................................................................

Master cylinder type

25,4 mm (1.0 in) diameter, tandem

.........................................................

Pressure reducing valve, failure conscious

Cut-in pressure, 90 - 24 bar (360 Ibf/in

2

) ratio 4.0:1,

......................

110 - 43 bar (645 Ibf/in

2

) ratio 2.9:1*

NOTE: * Pressure reducing valves are not fitted to all 110 specifications.
