COURTESY LIGHTS - Wiring diagram

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
C30	Left rear earth
D30	Rear coupling for /front door. driver's side
D31	Front passenger door/ rear coupling.
E50	Instrument panel	5560B
G10	Front courtesy light	7040E
H50	Electric window switch on .front passenger door	7005M
M1	Body computer	5505A
M66	Driver's door control unit	5505A
M67	Passenger door control unit	5505A
N50	Front driver's door lock geared motor.	7005N
N51	Front passenger door lock geared motor	7005N
N51	Passenger side front door lock geared motor	7005N
