HORNS - Wiring diagram

Wiring diagram

HORNS - Wiring diagram

COMPONENTS

Component codeNameAssembly reference
A1Battery5530B
B1Engine compartment junction unit5505A
B2Junction unit under dashboard5505A
C10Front left earth
D1Front / dashboard coupling
D47Clock spring coupling5580C
H1Ignition switch5520A
P5Horn5550B
P31Right rear speaker5580T
