C10 Front left earth

Make

Lancia

Model

Ypsilon Factory Service Manual

Year

2003–2011

Section

Earths › C10 Front left earth

Connectors and pin-outsC10 Front left earth

C10 Front left earth

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1.5	N		P5B	1
2		NZ		K25	2
3		NS		B1A	26
5	2.5	N		N15	4
6	2.5	N		H5A	7
7	1.5	N		F10	14
8	1.5	N		F11	14
9		NZ		F10	5
10		NZ		F11	5
15	2.5	N		N47
