21 · General

A030 Ignition coil

Make: Lancia
Model: Thesis Factory Service Manual
Year: 2002–2009
Section: Starting - recharging › A030 Ignition coil

‹ Prev A020 Starter motor Next › A040 Heater plugs

Connectors and pin-outsA030 Ignition coil

A030 Ignition coil

A030A – Engine

2.4 20V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	G		M010B	16
2	0,75	M	X	C040	B
				A030B	2
				A030C	2
				A030D	2
				A030E	2
3	0,75	G	X	A030B	3
				A030C	3
				A030D	3
				A030E	3

3.2 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

3.0 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	AR		M010B	16
2	0,75	NS		C040	1
3	0,75	RZ	X	A030B	3
				A030E	3
				A030C	3
				A030D	3
				A030F	3
				D004	1
				N070D	1
				N070F	1
				N070C	1
				N070A	1
				N070B	1
				N070E	1

2.0 TB

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	AR		M010B	16
2	0,75	NS		C040	1
3	0,75	RZ	X	D004	1
				A030D	3
				A030E	3
				A030C	3
				A030B	3
				N070B	1
				N070D	1
				N070E	1
				N070A	1
				N070C	1

A030B – Engine

2.4 20V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	V		M010B	32
2	0,75	M	X	C040	B
				A030A	2
				A030C	2
				A030D	2
				A030E	2
3	0,75	G	X	A030A	3
				A030C	3
				A030D	3
				A030E	3

3.2 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

3.0 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	MR		M010B	15
2	0,75	NS		C040	1
3	0,75	RZ	X	A030A	3
				A030E	3
				A030C	3
				A030D	3
				A030F	3
				D004	1
				N070D	1
				N070F	1
				N070C	1
				N070A	1
				N070B	1
				N070E	1

2.0 TB

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	MR		M010B	32
2	0,75	NS		C040	1
3	0,75	RZ	X	D004	1
				A030D	3
				A030E	3
				A030C	3
				A030A	3
				N070B	1
				N070D	1
				N070E	1
				N070A	1
				N070C	1

A030C – Engine

2.4 20V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	G		M010B	14
2	0,75	M	X	C040	B
				A030A	2
				A030B	2
				A030D	2
				A030E	2
3	0,75	G	X	A030A	3
				A030B	3
				A030D	3
				A030E	3

3.2 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

3.0 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	BN		M010B	14
2	0,75	NS		C040	1
3	0,75	RZ	X	A030A	3
				A030B	3
				A030E	3
				A030D	3
				A030F	3
				D004	1
				N070D	1
				N070F	1
				N070C	1
				N070A	1
				N070B	1
				N070E	1

2.0 TB

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	BN		M010B	14
2	0,75	NS		C040	1
3	0,75	RZ	X	D004	1
				A030D	3
				A030E	3
				A030A	3
				A030B	3
				N070B	1
				N070D	1
				N070E	1
				N070A	1
				N070C	1

A030D – Engine

2.4 20V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	G		M010B	15
2	0,75	M	X	A030E	2
				A030C	2
				A030B	2
				A030A	2
				C040	B
3	0,75	G	X	A030E	3
				A030C	3
				A030B	3
				A030A	3

3.2 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

3.0 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	LN		M010B	32
2	0,75	NS		C040	1
3	0,75	RZ	X	A030A	3
				A030B	3
				A030E	3
				A030C	3
				A030F	3
				D004	1
				N070D	1
				N070F	1
				N070C	1
				N070A	1
				N070B	1
				N070E	1

2.0 TB

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	LN		M010B	15
2	0,75	NS		C040	1
3	0,75	RZ	X	D004	1
				A030E	3
				A030C	3
				A030A	3
				A030B	3
				N070B	1
				N070D	1
				N070E	1
				N070A	1
				N070C	1

A030E – Engine

2.4 20V

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	V		M010B	31
2	0,75	M	X	C040	B
				A030A	2
				A030B	2
				A030D	2
				A030C	2
3	0,75	G	X	A030A	3
				A030B	3
				A030D	3
				A030C	3

3.2 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

3.0 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	AN		M010B	31
2	0,75	NS		C040	1
3	0,75	RZ	X	A030A	3
				A030B	3
				A030C	3
				A030D	3
				A030F	3
				D004	1
				N070D	1
				N070F	1
				N070C	1
				N070A	1
				N070B	1
				N070E	1

2.0 TB

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	AN		M010B	31
2	0,75	NS		C040	1
3	0,75	RZ	X	D004	1
				A030D	3
				A030C	3
				A030A	3
				A030B	3
				N070B	1
				N070D	1
				N070E	1
				N070A	1
				N070C	1

A030F – Engine

3.2 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

3.0 V6

Wiring	Colour
50 ENGINE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	GN		M010B	30
2	0,75	NS		C040	1
3	0,75	RZ	X	A030A	3
				A030B	3
				A030E	3
				A030C	3
				A030D	3
				D004	1
				N070D	1
				N070F	1
				N070C	1
				N070A	1
				N070B	1
				N070E	1
