Lancia Thesis Factory Service Manual (2002-2009)21 · Connectors and pin-outs
21 · General

D073 Trailer preparation coupling

Make
Lancia
Model
Thesis Factory Service Manual
Year
2002–2009
Section
Intermediate couplings › D073 Trailer preparation coupling
Connectors and pin-outsD073 Trailer preparation coupling

D073 Trailer preparation coupling

2.4 20V

D073 Trailer preparation coupling
WiringColour
25 REAR
PinCableDestination
DiameterColourNodeConnectorPin
10,35BNM084C5
2100,5LRB002D13
30,5BVF0313
40,5BGF0303

2.0 TB

D073 Trailer preparation coupling
WiringColour
25 REAR
PinCableDestination
DiameterColourNodeConnectorPin
10,35BNM084C5
2100,5LRB002D13
30,5BVF0313
40,5BGF0303

2.4 JTD 10V

D073 Trailer preparation coupling
WiringColour
25 REAR
PinCableDestination
DiameterColourNodeConnectorPin
10,35BNM084C5
2100,5LRB002D13
30,5BVF0313
40,5BGF0303

3.0 V6

D073 Trailer preparation coupling
WiringColour
25 REAR
PinCableDestination
DiameterColourNodeConnectorPin
10,35BNM084C5
2100,5LRB002D13
30,5BVF0313
40,5BGF0303
