Lancia Thesis Factory Service Manual (2002-2009)21 · Connectors and pin-outs

21 · General

D001 Front/dashboard coupling

Make: Lancia
Model: Thesis Factory Service Manual
Year: 2002–2009
Section: Intermediate couplings › D001 Front/dashboard coupling

‹ Prev C094 Passive entry aerial earth Next › D006 Front/rear coupling

Connectors and pin-outsD001 Front/dashboard coupling

D001 Front/dashboard coupling

3.2 V6

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

2.4 20V

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,35	VB	X	M058A	1
				I031	4
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LG		H005A	2

2.4 JTD 10V

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,35	VB	X	M058A	1
				I031	4
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LG		H005A	2

3.0 V6

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,5	VB		I035	2
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LG		H005A	2

2.4 JTD 20V

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,35	VB	X	M058A	1
				I031	4
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LO		H005A	2

2.0 TB

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,35	VB	X	M058A	1
				I031	4
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LG		H005A	2

2.4 20V

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,5	VB		I035	2
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LG		H005A	2

2.4 JTD 20V

D001 Front/dashboard coupling

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		D097C	7
A3	0,35	BH		M046	6
A4	1	LV		M046	21
A5	0,5	LR		M088	1
A6	0,35	SZ		M088	3
A7	0,5	VB		I035	2
B2	0,35	BV		M073	2
B3	0,35	BZ		D098	1
B4	0,35	BL		K026	1
B5	0,35	LG		H005A	2

2.4 20V

D001 Front/dashboard coupling

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		M001D	11
A3	0,35	BH		E050A	8
A4	1	LV		D097I	4
A5	0,5	LR		D097I	3
A6	0,35	sz		E050B	16
A7	0,35	VB		M001D	17
B2	0,35	BV		E050B	12
B3	0,35	BZ		M065A	21
B4	0,35	BL		M065A	22
B5	0,35	LG		B002H	13

2.0 TB

D001 Front/dashboard coupling

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		M001D	11
A3	0,35	BH		E050A	8
A4	1	LV		D097I	4
A5	0,5	LR		D097I	3
A6	0,35	sz		E050B	16
A7	0,35	VB		M001D	17
B2	0,35	BV		E050B	12
B3	0,35	BZ		M065A	21
B4	0,35	BL		M065A	22
B5	0,35	LG		B002H	13

2.4 JTD 10V

D001 Front/dashboard coupling

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		M001D	11
A3	0,35	BH		E050A	8
A4	1	LV		D097I	4
A5	0,5	LR		D097I	3
A6	0,35	sz		E050B	16
A7	0,35	VB		M001D	17
B2	0,35	BV		E050B	12
B3	0,35	BZ		M065A	21
B4	0,35	BL		M065A	22
B5	0,35	LG		B002H	13

3.0 V6

D001 Front/dashboard coupling

Wiring	Colour
20 DASHBOARD

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
A2	0,5	BR		M001D	11
A3	0,35	BH		E050A	8
A4	1	LV		D097I	4
A5	0,5	LR		D097I	3
A6	0,35	sz		E050B	16
A7	0,35	VB		M001D	17
B2	0,35	BV		E050B	12
B3	0,35	BZ		M065A	21
B4	0,35	BL		M065A	22
B5	0,35	LG		B002H	13
