Connectors and pin-outsC031 Right rear earth

C031 Right rear earth

2.4 20V

C031 Right rear earth

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	N		P052	3
2	0,5	N		B045	38
3	0,35	NZ		B045	44
7	200,5	N		A055B	1
10	200,5	N		D032	G
11	100,5	NZ		D040	7
12	0,5	N		C058	1
13	0,5	N		F031	2
15	0,35	NZ		M084C	8
16	0,35	NZ		B045	41

2.0 TB

C031 Right rear earth

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	N		P052	3
2	0,5	N		B045	38
3	0,35	NZ		B045	44
7	200,5	N		A055B	1
10	200,5	N		D032	G
11	100,5	NZ		D040	7
12	0,5	N		C058	1
13	0,5	N		F031	2
15	0,35	NZ		M084C	8
16	0,35	NZ		B045	41

2.4 JTD 10V

C031 Right rear earth

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	N		P052	3
2	0,5	N		B045	38
3	0,35	NZ		B045	44
7	200,5	N		A055B	1
10	200,5	N		D032	G
11	100,5	NZ		D040	7
12	0,5	N		C058	1
13	0,5	N		F031	2
15	0,35	NZ		M084C	8
16	0,35	NZ		B045	41

3.0 V6

C031 Right rear earth

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	100,5	N		P052	3
2	0,5	N		B045	38
3	0,35	NZ		B045	44
7	200,5	N		A055B	1
10	200,5	N		D032	G
11	100,5	NZ		D040	7
12	0,5	N		C058	1
13	0,5	N		F031	2
15	0,35	NZ		M084C	8
16	0,35	NZ		B045	41
