C030 Left rear earth

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Earths › C030 Left rear earth

Connectors and pin-outsC030 Left rear earth

C030 Left rear earth

2.4 20V

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
4	0,5	N		F040	1
6	0,5	N		F030	2
8	200,5	N		M063A	12
10	200,5	N		M063B	12
11	0,5	N		C059	1
3	0,35	NZ		G020	8
1	0,5	N		M063G	35
2	0,5	N		D035	19

2.0 TB

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
3	0,35	NZ		G020	8
4	0,5	N		F040	1
6	0,5	N		F030	2
8	200,5	N		M063A	12
10	200,5	N		M063B	12
11	0,5	N		C059	1
1	0,5	N		M063G	35
2	0,5	N		D035	19

2.4 JTD 10V

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
3	0,35	NZ		G020	8
4	0,5	N		F040	1
6	0,5	N		F030	2
8	200,5	N		M063A	12
10	200,5	N		M063B	12
11	0,5	N		C059	1
1	0,5	N		M063G	35
2	0,5	N		D035	19

3.0 V6

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
3	0,35	NZ		G020	8
4	0,5	N		F040	1
6	0,5	N		F030	2
8	200,5	N		M063A	12
10	200,5	N		M063B	12
11	0,5	N		C059	1
1	0,5	N		M063G	35
2	0,5	N		D035	19
