H090 switch control unit

Connectors and pin-outsH090 switch control unit

H090 SWITCH CONTROL UNIT

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 20 DASHBOARD	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,35	AV		See M001F BODY COMPUTER (FACIA)	29
2	0,35	HM		See M001F BODY COMPUTER (FACIA)	32
4	0,35	BH		See M001F BODY COMPUTER (FACIA)	35
5	0,35	GR		See M001F BODY COMPUTER (FACIA)	34
6	0,35	GV		See B002G JUNCTION UNIT UNDER DASHBOARD (FACIA)	12
7	0,35	NV		See C015A FACIA EARTH, DRIVER'S SIDE (FACIA)	12

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 20 DASHBOARD	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
16	0,35	AV		See M001E BODY COMPUTER (FACIA)	20

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Cargo trim level, MY 2005, Right hand drive

Wiring	Colour
See 20 DASHBOARD	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AN		See D020A FACIA/REAR JUNCTION (FACIA)	10
2	1,5	N		See C015A FACIA EARTH, DRIVER'S SIDE (FACIA)	8
3	1,5	SN		See B002E JUNCTION UNIT UNDER DASHBOARD (FACIA)	19
4	1,5	RG		See D020A FACIA/REAR JUNCTION (FACIA)	20
5	1,5	S		See B002E JUNCTION UNIT UNDER DASHBOARD (FACIA)	20
6	1,5	GV		See D020A FACIA/REAR JUNCTION (FACIA)	1
7	1,5	ZG		See D020A FACIA/REAR JUNCTION (FACIA)	11
8	1,5	NZ		See C015A FACIA EARTH, DRIVER'S SIDE (FACIA)	9

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Cargo trim level, MY 2005

Wiring	Colour
See 20 DASHBOARD	GRIGIO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	GV		See D020A FACIA/REAR JUNCTION (FACIA)	1
2	1,5	N		See C015A FACIA EARTH, DRIVER'S SIDE (FACIA)	8
3	1,5	SN		See B002E JUNCTION UNIT UNDER DASHBOARD (FACIA)	19
4	1,5	ZG		See D020A FACIA/REAR JUNCTION (FACIA)	11
5	1,5	S		See B002E JUNCTION UNIT UNDER DASHBOARD (FACIA)	20
6	1,5	AN		See D020A FACIA/REAR JUNCTION (FACIA)	10
7	1,5	RG		See D020A FACIA/REAR JUNCTION (FACIA)	20
8	1,5	NZ		See C015A FACIA EARTH, DRIVER'S SIDE (FACIA)	9

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	bianco

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2430555555555,56	AV		See M1F BODY COMPUTER ( FACIA )	29
2	2430555555555,56	HM		See M1F BODY COMPUTER ( FACIA )	32
4	2430555555555,56	BH		See M1F BODY COMPUTER ( FACIA )	35
5	2430555555555,56	GR		See M1F BODY COMPUTER ( FACIA )	34
6	2430555555555,56	GV		See B2G JUNCTION UNIT UNDER DASHBOARD ( FACIA )	12
7	2430555555555,56	NV		See C15B FACIA EARTH, DRIVER'S SIDE ( FACIA )	2

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	grigio

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
16	2430555555555,56	AV		See M1E BODY COMPUTER ( FACIA )	20

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	bianco

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AN		See D20 DASHBOARD/REAR COUPLING ( REAR )
2	1,5	N		See C15A FACIA EARTH, DRIVER'S SIDE ( FACIA )	8
3	1,5	SN		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	19
4	1,5	RG		See D20 DASHBOARD/REAR COUPLING ( REAR )
5	1,5	S		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	20
6	1,5	GV		See D20 DASHBOARD/REAR COUPLING ( REAR )
7	1,5	ZG		See D20 DASHBOARD/REAR COUPLING ( REAR )
8	1,5	NZ		See C15A FACIA EARTH, DRIVER'S SIDE ( FACIA )	9

Wiring	Colour
See 20 DASHBOARD	bianco

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	GV		See D20 DASHBOARD/REAR COUPLING ( REAR )
2	1,5	N		See C15A FACIA EARTH, DRIVER'S SIDE ( FACIA )	8
3	1,5	SN		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	19
4	1,5	ZG		See D20 DASHBOARD/REAR COUPLING ( REAR )
5	1,5	S		See B2E JUNCTION UNIT UNDER DASHBOARD ( FACIA )	20
6	1,5	AN		See D20 DASHBOARD/REAR COUPLING ( REAR )
7	1,5	RG		See D20 DASHBOARD/REAR COUPLING ( REAR )
8	1,5	NZ		See C15A FACIA EARTH, DRIVER'S SIDE ( FACIA )	9
