D097 short circuiting coupling

Make: Fiat
Model: Doblò Factory Service Manual
Year: 2000–2010
Section: Intermediate couplings › D097 short circuiting coupling

‹ Prev D085 tailgate/rear seal Next › D099 radio phone preparation coupling

Connectors and pin-outsD097 short circuiting coupling

D097 SHORT CIRCUITING COUPLING

D097A – Rear

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	H		See D030 REAR/DRIVER'S FRONT DOOR COUPLING	1
2	1,5	SN		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	16
3	1,5	H		See D031 REAR/PASSENGER FRONT DOOR COUPLING	1
4	1,5	H		See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR )	1
5	1,5	H		See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR )	1
6	1,5	H		See D085A TAILGATE REAR SEAL/ (LEFT SWING DOOR)	3

D097B – Facia

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005, Right hand drive

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	BN		See P020B RADIO (FACIA)	4
2	1,5	BN		See P038 RIGHT FRONT SPEAKER IN DASHBOARD	2
3	1,5	BN		See D020A FACIA/REAR JUNCTION (FACIA)	2
4	1,5	RN		See P020B RADIO (FACIA)	3
5	1,5	RN		See P038 RIGHT FRONT SPEAKER IN DASHBOARD	1
6	1,5	RN		See D020A FACIA/REAR JUNCTION (FACIA)	3

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	BN		See P020B RADIO (FACIA)	6
2	1,5	BN		See P037 LEFT FRONT SPEAKER IN DASHBOARD	2
3	1,5	BN		See D020A FACIA/REAR JUNCTION (FACIA)	2
4	1,5	RN		See P020B RADIO (FACIA)	5
5	1,5	RN		See P037 LEFT FRONT SPEAKER IN DASHBOARD	1
6	1,5	RN		See D020A FACIA/REAR JUNCTION (FACIA)	3

D097C – Rear

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Long wheelbase version, MY 2005, Sliding door

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	G		See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR )	2
2	1,5	G		See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR )	2
3	1,5	G		See D030 REAR/DRIVER'S FRONT DOOR COUPLING	2
4	1,5	G		See D031 REAR/PASSENGER FRONT DOOR COUPLING	2
5	1,5	G		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	18
6	1,5	G		See D085A TAILGATE REAR SEAL/ (LEFT SWING DOOR)	6
7	1,5	GN		See M001A BODY COMPUTER (REAR)	33
8	1,5	GN		See G020 REAR (CENTRE) COURTESY LIGHT	2
9	1,5	GN		See G025 LEFT REAR COURTESY LIGHT	2

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	G		See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR )	2
2	1,5	G		See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR )	2
3	1,5	G		See D030 REAR/DRIVER'S FRONT DOOR COUPLING	2
4	1,5	G		See D031 REAR/PASSENGER FRONT DOOR COUPLING	2
5	1,5	G		See B002D JUNCTION UNIT UNDER DASHBOARD (REAR)	18
6	1,5	G		See D085A TAILGATE REAR SEAL/ (LEFT SWING DOOR)	6
7	1,5	CN		See P092 SUBWOOFER	1
8	1,5	CN		See P030 LEFT REAR SPEAKER	1
9	1,5	CN		See D020A FACIA/REAR JUNCTION (FACIA)	6

D097D – Facia

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · HIGH car radio, MY 2005, Right hand drive

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ		See P020B RADIO (FACIA)	6
2	1,5	NZ		See P037B LEFT FRONT SPEAKER IN DASHBOARD (FACIA)	2
3	1,5	NZ		See D020A FACIA/REAR JUNCTION (FACIA)	4
4	1,5	SN		See P020B RADIO (FACIA)	5
5	1,5	SN		See P037B LEFT FRONT SPEAKER IN DASHBOARD (FACIA)	1
6	1,5	SN		See D020A FACIA/REAR JUNCTION (FACIA)	5
7	1	H		See P025 AERIAL POWER SUPPLY	1
8	1	H		See D020A FACIA/REAR JUNCTION (FACIA)	15
9	1	H		See P020A RADIO (FACIA)	5

1.4 8v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005, Right hand drive

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ		See P020B RADIO (FACIA)	6
2	1,5	NZ		See P037B LEFT FRONT SPEAKER IN DASHBOARD (FACIA)	2
3	1,5	NZ		See D020A FACIA/REAR JUNCTION (FACIA)	4
4	1,5	SN		See P020B RADIO (FACIA)	5
5	1,5	SN		See P037B LEFT FRONT SPEAKER IN DASHBOARD (FACIA)	1
6	1,5	SN		See D020A FACIA/REAR JUNCTION (FACIA)	5

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · HIGH car radio, MY 2005

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ		See P020B RADIO (FACIA)	4
2	1,5	NZ		See P038B RIGHT FRONT SPEAKER IN DASHBOARD (FACIA)	2
3	1,5	NZ		See D020A FACIA/REAR JUNCTION (FACIA)	4
4	1,5	M		See P020B RADIO (FACIA)	3
5	1,5	SN		See P038B RIGHT FRONT SPEAKER IN DASHBOARD (FACIA)	1
6	1,5	SN		See D020A FACIA/REAR JUNCTION (FACIA)	5
7	1	H		See P025 AERIAL POWER SUPPLY	1
8	1	H		See D020A FACIA/REAR JUNCTION (FACIA)	15
9	1	H		See P020A RADIO (FACIA)	5

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 20 DASHBOARD	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ		See P020B RADIO (FACIA)	4
2	1,5	NZ		See P038B RIGHT FRONT SPEAKER IN DASHBOARD (FACIA)	2
3	1,5	NZ		See D020A FACIA/REAR JUNCTION (FACIA)	4
4	1,5	M		See P020B RADIO (FACIA)	3
5	1,5	SN		See P038B RIGHT FRONT SPEAKER IN DASHBOARD (FACIA)	1
6	1,5	SN		See D020A FACIA/REAR JUNCTION (FACIA)	5

D097E – Rear

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AG		See P092 SUBWOOFER	2
2	1,5	AG		See P031 RIGHT REAR SPEAKER	1
3	1,5	AG		See D020A FACIA/REAR JUNCTION (FACIA)	8
4	1,5	CV		See P092 SUBWOOFER	4
5	1,5	CV		See P030 LEFT REAR SPEAKER	2
6	1,5	CV		See D020A FACIA/REAR JUNCTION (FACIA)	7
7	1,5	AR		See P092 SUBWOOFER	5
8	1,5	AR		See P031 RIGHT REAR SPEAKER	2
9	1,5	AR		See D020A FACIA/REAR JUNCTION (FACIA)	9

D97A – Rear

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	H		See D30 FRONT LEFT DOOR CONNECTION ( REAR )	1
2	1,5	SN		See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR )	16
3	1,5	H		See D031 REAR/PASSENGER FRONT DOOR COUPLING	1
4	1,5	H		See D36B REAR RIGHT DOOR CONNECTION ( REAR )	1
5	1,5	H		See D35B REAR LEFT DOOR CONNECTION ( REAR )	1
6	1,5	H		See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE )	3
8	0,5	B
9	0,5	GV		See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR )	7

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	H		See D30 FRONT LEFT DOOR CONNECTION ( REAR )	1
2	1,5	SN		See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR )	16
3	1,5	H		See D031 REAR/PASSENGER FRONT DOOR COUPLING	1
4	1,5	H		See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR )	1
5	1,5	H		See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR )	1
6	1,5	H		See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE )	3
7	0,5	B		See D20 DASHBOARD/REAR COUPLING ( REAR )
8	0,5	GV		See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR )	7
9	0,35	CB		See M084 PARKING SENSOR ECU	1

D97B – Facia

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	BN		See P20B CAR RADIO ( FACIA )	6
2	1,5	BN		See P037 LEFT FRONT SPEAKER IN DASHBOARD	2
3	1,5	BN		See D20 DASHBOARD/REAR COUPLING ( REAR )
4	1,5	RN		See P20B CAR RADIO ( FACIA )	5
5	1,5	RN		See P037 LEFT FRONT SPEAKER IN DASHBOARD	1
6	1,5	RN		See D20 DASHBOARD/REAR COUPLING ( REAR )

D97C – Rear

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
23	1,5	G		See D36B REAR RIGHT DOOR CONNECTION ( REAR )	2
24	1,5	G		See D35B REAR LEFT DOOR CONNECTION ( REAR )	2
25	1,5	G		See D30 FRONT LEFT DOOR CONNECTION ( REAR )	2
26	1,5	G		See D031 REAR/PASSENGER FRONT DOOR COUPLING	2
27	1,5	G		See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR )	18
28	1,5	G		See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE )	6

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · HIGH car radio

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	G		See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR )	2
2	1,5	G		See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR )	2
3	1,5	G		See D30 FRONT LEFT DOOR CONNECTION ( REAR )	2
4	1,5	G		See D031 REAR/PASSENGER FRONT DOOR COUPLING	2
5	1,5	G		See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR )	18
6	1,5	G		See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE )	6
7	1,5	CN		1
8	1,5	CN		See P030 LEFT REAR SPEAKER	1
9	1,5	CN		See D20 DASHBOARD/REAR COUPLING ( REAR )

D97D – Facia

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 20 DASHBOARD	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ		See P20B CAR RADIO ( FACIA )	4
2	1,5	NZ		See P38B RIGHT FRONT SPEAKER IN DASHBOARD ( FACIA )	1
3	1,5	NZ		See D20 DASHBOARD/REAR COUPLING ( REAR )
4	1,5	SN		See P20B CAR RADIO ( FACIA )	3
5	1,5	SN		See P38B RIGHT FRONT SPEAKER IN DASHBOARD ( FACIA )	2
6	1,5	SN		See D20 DASHBOARD/REAR COUPLING ( REAR )

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · HIGH car radio

Wiring	Colour
See 20 DASHBOARD	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	NZ		See P20B CAR RADIO ( FACIA )	4
2	1,5	NZ		See P38B RIGHT FRONT SPEAKER IN DASHBOARD ( FACIA )	2
3	1,5	NZ		See D20 DASHBOARD/REAR COUPLING ( REAR )
4	1,5	SN		See P020 RADIO	3
5	1,5	SN		See P38B RIGHT FRONT SPEAKER IN DASHBOARD ( FACIA )	1
6	1,5	SN		See D20 DASHBOARD/REAR COUPLING ( REAR )
7		H		See P25 AERIAL FEEDER/AMPLIFIER ( FACIA )	1
8		H		See D20 DASHBOARD/REAR COUPLING ( REAR )
9		H		See P20A CAR RADIO ( FACIA )	5

D97E – Rear

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · HIGH car radio

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	AG		2
2	1,5	AG		See P031 RIGHT REAR SPEAKER	1
3	1,5	AG		See D20 DASHBOARD/REAR COUPLING ( REAR )
4	1,5	CV		4
5	1,5	CV		See P030 LEFT REAR SPEAKER	2
6	1,5	CV		See D20 DASHBOARD/REAR COUPLING ( REAR )
7	1,5	AR		5
8	1,5	AR		See P031 RIGHT REAR SPEAKER	2
9	1,5	AR		See D20 DASHBOARD/REAR COUPLING ( REAR )
