F010 left headlamp

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Exterior lights › F010 left headlamp

Connectors and pin-outsF010 left headlamp

F010 LEFT HEADLAMP

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Wiring	Colour
See 12 FRONT	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	SB		See M001C BODY COMPUTER (FRONT)	38
2	0,75	HN		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	3
4	0,5	H		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	2
5	1	N		See C010 LEFT FRONT EARTH	6
6	0,35	BV		See B002A JUNCTION UNIT UNDER DASHBOARD (FRONT)	1
8	0,5	N		See C010 LEFT FRONT EARTH	4
9	0,5	GV		See M001C BODY COMPUTER (FRONT)	40
10	0,5	V		See B001B JUNCTION UNIT (FRONT)	25

F10 – Front

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 12 FRONT	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
A		SB		See M1C BODY COMPUTER ( FRONT )	38
B		GV		See M1C BODY COMPUTER ( FRONT )	40
C		V		See B1B ENGINE COMPARTMENT JUNCTION UNIT ( FRONT )	25
D	1	HN		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	3
E	1	H		See B1B ENGINE COMPARTMENT JUNCTION UNIT ( FRONT )	4
F		VB		See B2A JUNCTION UNIT UNDER DASHBOARD ( FRONT )	1
G	1	N		See C010 LEFT FRONT EARTH	4
H	1	N		See C010 LEFT FRONT EARTH	3
