C060 INJECTION ECU EARTH

1.3 JTD 16V · from 12/03 · MY 2005

Wiring	Colour
See 51 INJECTION BRIDGE / ENGINE SERVICES	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	4	N		See M010C ENGINE MANAGEMENT ECU (INJECTION BRAID / ENGINE SERVICES)	1

C060A – Engine

1.6 16v · from 12/03 · BIPOWER, MY 2005

Wiring	Colour
See 50 ENGINE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	4	N	X	See M010B ENGINE MANAGEMENT ECU (ENGINE)	28
				See M010B ENGINE MANAGEMENT ECU (ENGINE)	27

C060B – Engine

1.6 16v · from 12/03 · BIPOWER, MY 2005

Wiring	Colour
See 50 ENGINE	_

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	2,5	N	X	See M019B METHANE INJECTION CONTROL UNIT (ENGINE)	76
				See M019B METHANE INJECTION CONTROL UNIT (ENGINE)	61
				See M019B METHANE INJECTION CONTROL UNIT (ENGINE)	62
				See M019B METHANE INJECTION CONTROL UNIT (ENGINE)	55
				See M019A METHANE INJECTION CONTROL UNIT (ENGINE)	27

C60 – Engine

1.2 8v

Wiring	Colour
See 50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	4	N		See M10C ENGINE MANAGEMENT ECU ( ENGINE )	1

1.9 JTD 8V

Wiring	Colour
See 50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	N	x	See M15A HEATER PLUGS CONTROLUNIT ( ENGINE )	1
			x	See M10B ENGINE MANAGEMENT ECU ( ENGINE )	3
			x	See O20 DIESEL PREHEATING RESISTOR	1
			x	See M10B ENGINE MANAGEMENT ECU ( ENGINE )	2
			x	See M10B ENGINE MANAGEMENT ECU ( ENGINE )	1
			x	See K31 WATER IN DIESEL FILTER SENSOR ( ENGINE )	2

1.6 16v

Wiring	Colour
See 50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
		N	X	See M19A METHANE INJECTION CONTROL UNIT ( ENGINE )	27
				See M19B METHANE INJECTION CONTROL UNIT ( ENGINE )	55
				See M19B METHANE INJECTION CONTROL UNIT ( ENGINE )	61
				See M19B METHANE INJECTION CONTROL UNIT ( ENGINE )	62
				See M19B METHANE INJECTION CONTROL UNIT ( ENGINE )	76
	4	N	X	See M10A ENGINE MANAGEMENT ECU ( ENGINE )	27
				See M10A ENGINE MANAGEMENT ECU ( ENGINE )	28

1.3 JTD 16V

Wiring	Colour
See 50 ENGINE

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	4	N		See M10C ENGINE MANAGEMENT ECU ( ENGINE )	1
