AIRBAG - LOCATION OF COMPONENTS

Location of components

Components

Component code	Name	Assembly reference
B1	JUNCTION UNIT
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
B5	MAXI FUSE-1 BOX
B99	MAXIFUSE BOX ON BATTERY	Op. 5530B BATTERY AND LEADS
C15	FACIA EARTH, DRIVER''S SIDE
C50	AIR BAG EARTH
D47	CLOCK SPRING ON STEERING WHEEL	Op. 5580C AIR BAG SYSTEM
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H1	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
H75	PASSENGER''S AIR BAG DISABLEMENT SWITCH ( FACIA )	Op. 5580C AIR BAG SYSTEM
K66	SENSOR FOR DRIVER''S SIDE BAG ( REAR )	Op. 5580C AIR BAG SYSTEM
K67	SENSOR FOR PASSENGER SIDE BAG ( REAR )	Op. 5580C AIR BAG SYSTEM
M1	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M60	AIR BAG CONTROL UNIT	Op. 5580C AIR BAG SYSTEM
Q9	DRIVER''S AIR BAG	Op. 5580C AIR BAG SYSTEM
Q11	AIR BAG IN DASHBOARD (PASSENGER SIDE) ( FACIA )	Op. 5580C AIR BAG SYSTEM
Q20	DRIVER''S SEAT BELT PRE-TENSIONER	Op. 7065A FRONT SEAT BELTS
Q21	FRONT PASSENGER SEAT BELT PRE-TENSIONER	Op. 7065A FRONT SEAT BELTS
Q30	DRIVER''S SIDE BAG ( REAR )	Op. 5580C AIR BAG SYSTEM
Q31	PASSENGER SIDE BAG ( REAR )	Op. 5580C AIR BAG SYSTEM
Q40	DRIVER''S HEAD BAG ( REAR )	Op. 5580C AIR BAG SYSTEM
Q41	PASSENGER HEAD BAG ( REAR )	Op. 5580C AIR BAG SYSTEM
