Wiring diagrams and electrical functionsConnect - wiring diagram
CONNECT - WIRING DIAGRAM
Wiring diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | JUNCTION UNIT | |
| B2 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B5 | MAXI FUSE-1 BOX | |
| B99 | MAXIFUSE BOX ON BATTERY | Op. 5530B BATTERY AND LEADS |
| C15 | FACIA EARTH, DRIVER''S SIDE | |
| D20 | REAR DASHBOARD COUPLING ( REAR ) | |
| H1 | IGNITION SWITCH | Op. 5520A IGNITION SWITCH |
| M1 | BODY COMPUTER | Op. 5505A MULTI-FUNCTION COMPONENTS |
| P20 | RADIO | Op. 5570T CAR RADIO AND CAR TELEPHONE |
| P20 | RADIO | Op. 5580P CONNECT PANEL |
| P25 | AERIAL AMPLIFIER FEEDER ( REAR ) | Op. 5570T CAR RADIO AND CAR TELEPHONE |
