D6 Front rear coupling

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Intermediate couplings › D6 Front rear coupling

Connectors and pin-outsD6 Front rear coupling

D6 Front rear coupling

Wiring	Colour
12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
8		M		M50	13
9		BL		M50	14
10		VN		M50	30
11		BN		M50	31
12		N		D97M	6
13		B		12
14		BR		D97M	9

Wiring	Colour
25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
8		M		K75	2
9		BL		K75	1
10		VN		K76	2
11		BN		K76	1
12		N		D105	3
13		B		D105	2
14		BR		D105	1
