SECURITY AND CENTRAL DOOR LOCKING SYSTEM COMPONENTS - FROM 02MY

Make

Land Rover

Model

Defender TD5 Defender

Section

SECURITY AND CENTRAL DOOR LOCKING SYSTEM COMPONENTS - FROM 02MY

ELECTRICALSECURITY AND CENTRAL DOOR LOCKING SYSTEM COMPONENTS - FROM 02MY

86

ELECTRICAL

2

DESCRIPTION AND OPERATION

SECURITY AND CENTRAL DOOR LOCKING
SYSTEM COMPONENTS - FROM 02MY

1. Engine immobilisation warning lamp
2. Security LED
3. Transponder coil
4. CDL actuators (tail door shown)
5. Immobilisation ECU (300Tdi models only)
6. Remote handset and key

7. Door switches
8. Bonnet switch
9. Alarm sounder

10. Battery Backed Up Sounder (BBUS)
11. Anti-theft alarm ECU
12. Volumetric sensor

32 Electrical
