SUPPLY - Wiring diagram
- Make
- Lancia
- Model
- Ypsilon Factory Service Manual
- Year
- 2003–2011
- Section
- Power supply and earths › SUPPLY - Wiring diagram
Wiring diagrams and electrical functionsSUPPLY - Wiring diagram
SUPPLY - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| A1 | Battery | 5530B |
| B1 | Engine compartment junction unit | 5505A |
| B2 | Junction unit under dashboard | 5505A |
| B37 | Spark plugs (MAXI FUSE) fuse | |
| B43 | Robot gearbox supply fuse | |
| B43 | Robot gearbox supply fuse. | |
| B98 | Additional fuse box | |
| B98 | Supplementary fuse box | |
| C2 | Battery earth on engine | |
| C3 | Battery earth on bodyshell | |
| H1 | Ignition switch | 5520A |
