Lancia Thesis Factory Service Manual (2002-2009)21 · Connectors and pin-outs
21 · General

P032 Centre front speaker

Make
Lancia
Model
Thesis Factory Service Manual
Year
2002–2009
Section
Various consumers › P032 Centre front speaker
Connectors and pin-outsP032 Centre front speaker

P032 Centre front speaker

2.4 20V

P032 Centre front speaker
WiringColour
20 DASHBOARD
PinCableDestination
DiameterColourNodeConnectorPin
1100,5BL-T44D02019
2100,5BN-T44D02018

2.0 TB

P032 Centre front speaker
WiringColour
20 DASHBOARD
PinCableDestination
DiameterColourNodeConnectorPin
1100,5BL-T44D02019
2100,5BN-T44D02018

2.4 JTD 10V

P032 Centre front speaker
WiringColour
20 DASHBOARD
PinCableDestination
DiameterColourNodeConnectorPin
1100,5BL-T44D02019
2100,5BN-T44D02018

3.0 V6

P032 Centre front speaker
WiringColour
20 DASHBOARD
PinCableDestination
DiameterColourNodeConnectorPin
1100,5BL-T44D02019
2100,5BN-T44D02018
