O025 Additional heater resistance

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Resistances and dimmers › O025 Additional heater resistance

Connectors and pin-outsO025 Additional heater resistance

O025 Additional heater resistance

O025A – Air conditioning

2.4 20V

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	B		D008B	A
2	4	B	X	C016B	1
				O025B	2

2.0 TB

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	B		D008B	A
2	4	B	X	C016B	1
				O025B	2

2.4 JTD 10V

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	B		D008B	A
2	4	B	X	C016B	1
				O025B	2

3.0 V6

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	B		D008B	A
2	4	B	X	C016B	1
				O025B	2

O025B – Air conditioning

2.4 20V

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	RN		D008B	B
2	4	RN	X	C016B	1
				O025A	2

2.0 TB

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	RN		D008B	B
2	4	RN	X	C016B	1
				O025A	2

2.4 JTD 10V

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	RN		D008B	B
2	4	RN	X	C016B	1
				O025A	2

3.0 V6

Wiring	Colour
65 AIR CONDITIONING

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	4	RN		D008B	B
2	4	RN	X	C016B	1
				O025A	2

21 General
