D190 Front/Webasto pump coupling

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Intermediate couplings › D190 Front/Webasto pump coupling

Connectors and pin-outsD190 Front/Webasto pump coupling

D190 Front/Webasto pump coupling

3.2 V6

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin

2.4 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

2.4 JTD 10V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

3.0 V6

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

2.4 JTD 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

2.0 TB

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

2.4 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

2.4 JTD 20V

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		M073	7
2	0,35	BZ		M073	25
3	0,35	NV		M073	12
4	1	NZ		D006	B6
5	1	RV		M075A	6

2.4 20V

Wiring	Colour
120 BRIDGE FOR TYRE INFLATION PRESSURE CONTROL UNIT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		K002	6
2	0,35	BZ		K002	5
3	0,35	NV		K002	1
4	1	NZ		N044	2
5	1	RV		N044	1

2.0 TB

Wiring	Colour
120 BRIDGE FOR TYRE INFLATION PRESSURE CONTROL UNIT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		K002	6
2	0,35	BZ		K002	5
3	0,35	NV		K002	1
4	1	NZ		N044	2
5	1	RV		N044	1

2.4 JTD 10V

Wiring	Colour
120 BRIDGE FOR TYRE INFLATION PRESSURE CONTROL UNIT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		K002	6
2	0,35	BZ		K002	5
3	0,35	NV		K002	1
4	1	NZ		N044	2
5	1	RV		N044	1

3.0 V6

Wiring	Colour
120 BRIDGE FOR TYRE INFLATION PRESSURE CONTROL UNIT

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,35	BH		K002	6
2	0,35	BZ		K002	5
3	0,35	NV		K002	1
4	1	NZ		N044	2
5	1	RV		N044	1
