D099 Radio phone preparation coupling

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Intermediate couplings › D099 Radio phone preparation coupling

Connectors and pin-outsD099 Radio phone preparation coupling

D099 Radio phone preparation coupling

2.4 20V

Wiring	Colour
78 CENTRE CONSOLE BRIDGE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
5	0,35	AR		D037	11
6	0,35	AN		D037	12
7	0,35	AZ		D037	13
8	0,35	AL		D037	14
9	0,35	AS		D037	15
10	0,35	AH		D037	16
11	0,35	AG		D037	17
12	0,35	AB		D037	18

2.0 TB

Wiring	Colour
78 CENTRE CONSOLE BRIDGE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
5	0,35	AR		D037	11
6	0,35	AN		D037	12
7	0,35	AZ		D037	13
8	0,35	AL		D037	14
9	0,35	AS		D037	15
10	0,35	AH		D037	16
11	0,35	AG		D037	17
12	0,35	AB		D037	18

2.4 JTD 10V

Wiring	Colour
78 CENTRE CONSOLE BRIDGE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
5	0,35	AR		D037	11
6	0,35	AN		D037	12
7	0,35	AZ		D037	13
8	0,35	AL		D037	14
9	0,35	AS		D037	15
10	0,35	AH		D037	16
11	0,35	AG		D037	17
12	0,35	AB		D037	18

3.0 V6

Wiring	Colour
78 CENTRE CONSOLE BRIDGE

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
5	0,35	AR		D037	11
6	0,35	AN		D037	12
7	0,35	AZ		D037	13
8	0,35	AL		D037	14
9	0,35	AS		D037	15
10	0,35	AH		D037	16
11	0,35	AG		D037	17
12	0,35	AB		D037	18
