C015 Driver's dashboard earth

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Earths › C015 Driver's dashboard earth

Connectors and pin-outsC015 Driver's dashboard earth

C015 Driver's dashboard earth

2.4 20V

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	NV		A050	3
3	0,5	N		D030	1
5	100,5	N		M095	10
7	200,5	N		D070B	F
8	200,5	N		D030	4
9	2	NV		I050	1
11	0,5	N		D070B	L
12	0,35	NZ		D037	2
13	0,35	NZ		G038	2
14	0,35	NZ		G039	2
15	0,35	NZ		G057	2
16	0,5	N		M062	1

2.0 TB

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	NV		A050	3
3	0,5	N		D030	1
5	100,5	N		M095	10
7	200,5	N		D070B	F
8	200,5	N		D030	4
9	2	NV		I050	1
11	0,5	N		D070B	L
12	0,35	NZ		D037	2
13	0,35	NZ		G038	2
14	0,35	NZ		G039	2
15	0,35	NZ		G057	2
16	0,5	N		M062	1

2.4 JTD 10V

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	NV		A050	3
3	0,5	N		D030	1
5	100,5	N		M095	10
7	200,5	N		D070B	F
8	200,5	N		D030	4
9	2	NV		I050	1
11	0,5	N		D070B	L
12	0,35	NZ		D037	2
13	0,35	NZ		G038	2
14	0,35	NZ		G039	2
15	0,35	NZ		G057	2
16	0,5	N		M062	1

3.0 V6

Wiring	Colour
25 REAR

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
1	0,75	NV		A050	3
3	0,5	N		D030	1
5	100,5	N		M095	10
7	200,5	N		D070B	F
9	2	NV		I050	1
11	0,5	N		D070B	L
12	0,35	NZ		D037	2
13	0,35	NZ		G038	2
14	0,35	NZ		G039	2
15	0,35	NZ		G057	2
16	0,5	N		M062	1
8	200,5	N		D030	4
