J5 Starting enablement relay

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Relays › J5 Starting enablement relay

Connectors and pin-outsJ5 Starting enablement relay

J5 Starting enablement relay

1.8 T.SPARK, 2.0 JTS · Smart gearbox

Wiring	Colour
12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		LN	X	B1A	20
				B1C	12
				M54A	28
3		MV		M54A	42
4	1,5	MV		D4A
5	1,5	MN	X	M54B	76
				H1A	3
