D75 Radio phone junction

Make

Alfa Romeo

Model

GT Factory Service Manual

Year

2003–2010

Section

Intermediate couplings › D75 Radio phone junction

Connectors and pin-outsD75 Radio phone junction

D75 Radio phone junction

Mobile phone pre-setting

Wiring	Colour
20 FACIA	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		BV		P20C	9
3		BN		P20C	8
4		BL		P20C	7
7		LV		D20	18
8		GV		D97D	3
9	1	RG		B2H	8
10		NZ		D97D	8
