Electrical equipmentCentre speaker in dashboard - r.r.
CENTRE SPEAKER IN DASHBOARD - R.R.
Removing
1. Working in the centre of the dashboard, place the air vents in the closed air flow position.
2. Undo the bolts.
3. Move the vent assembly (3a) slightly releasing the flexible retainers (3b).
4. Disconnect the electrical connection.
| Description | Component |
|---|---|
| CENTRAL FROMT SPEAKER | See P032 CENTRE FRONT SPEAKER |
5. Undo the bolts.
6. Remove the speaker.
Refitting
- Check that the front speaker is not damaged.
- Remove the speaker.
- Tighten the bolts.
- Connect the electrical connection.
- Position the vent assembly and attach the retainers.
- Tighten the bolts.
- Check that the speaker is working.
