H37 Gear controls

Make

Lancia

Model

Ypsilon Factory Service Manual

Year

2003–2011

Section

Manual electric controls › H37 Gear controls

Connectors and pin-outsH37 Gear controls

H37 Gear controls

1.4 16v, 1.3 JTD · Smart gearbox

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		C		M54B	65
2		H		M54A	26
3		B		M54B	68
4		M		M54B	67
5		S		M54B	74
6		CL	X	B1A	14
6		CL	X	B1A	20
6		CL	X	M54A	28
