EngineComposition
Composition
STRUCTURE
AIR SUPPLY SYSTEM.
- 1 Cold air intake.
- 2 Air cleaner assembly.
- 3 Air flow meter with built-in intake air temperature sensor [DF1056].
- 4 Intake manifold.
- 5 Turbocharger.
- 6 Intercooler.
STRUCTURE
AIR SUPPLY SYSTEM
- 1 Cold air intake
- 2 Air cleaner assembly
- 3 Air flow meter with air temperature sensor [DF 1056].
- 4 Throttle body built into DVE [DF 1056].
- 5 Resonator
STRUCTURE
AIR SUPPLY SYSTEM.
- 1 Cold air intake.
- 2 Air filter assembly.
- 3 Modular intake manifold [DF1072].
- 4 Intake manifold.
- 5 Throttle casing [DF1056]
- 6 Air flow meter with built-in intake air temperature sensor [DF1056].
