P075 CD Changer module

Make

Lancia

Model

Thesis Factory Service Manual

Year

2002–2009

Section

Various consumers › P075 CD Changer module

Connectors and pin-outsP075 CD Changer module

P075 CD Changer module

2.4 20V

Wiring	Colour
79 CD CHANGER

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
13	100,5	R		M065G	4
14	100,5	B		M065G	5
15	100,5	M		M065G	2
16	100,5	L		M065G	1
17	100,5	N		M065G	3
18	100,5			M065G	7
19	100,5	G		M065G	8
20	100,5	C		M065G	6

2.0 TB

Wiring	Colour
79 CD CHANGER

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
13	100,5	R		M065G	4
14	100,5	B		M065G	5
15	100,5	M		M065G	2
16	100,5	L		M065G	1
17	100,5	N		M065G	3
18	100,5			M065G	7
19	100,5	G		M065G	8
20	100,5	C		M065G	6

2.4 JTD 10V

Wiring	Colour
79 CD CHANGER

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
13	100,5	R		M065G	4
14	100,5	B		M065G	5
15	100,5	M		M065G	2
16	100,5	L		M065G	1
17	100,5	N		M065G	3
18	100,5			M065G	7
19	100,5	G		M065G	8
20	100,5	C		M065G	6

3.0 V6

Wiring	Colour
79 CD CHANGER

Pin	Cable		Destination
	Diameter	Colour	Node	Connector	Pin
13	100,5	R		M065G	4
14	100,5	B		M065G	5
15	100,5	M		M065G	2
16	100,5	L		M065G	1
17	100,5	N		M065G	3
18	100,5			M065G	7
19	100,5	G		M065G	8
20	100,5	C		M065G	6
