Lancia Thesis Factory Service Manual (2002-2009)21 · Connectors and pin-outs
21 · General

P045 Left front tweeter speaker

Make
Lancia
Model
Thesis Factory Service Manual
Year
2002–2009
Section
Various consumers › P045 Left front tweeter speaker
Connectors and pin-outsP045 Left front tweeter speaker

P045 Left front tweeter speaker

2.4 20V

P045 Left front tweeter speaker
WiringColour
30 LEFT FRONT DOOR
PinCableDestination
DiameterColourNodeConnectorPin
20,5MN-T1 1XP0352
D03015
30,5MB-T1 1XP0351
D03014

2.0 TB

P045 Left front tweeter speaker
WiringColour
30 LEFT FRONT DOOR
PinCableDestination
DiameterColourNodeConnectorPin
20,5MN-T1 1XP0352
D03015
30,5MB-T1 1XP0351
D03014

2.4 JTD 10V

P045 Left front tweeter speaker
WiringColour
30 LEFT FRONT DOOR
PinCableDestination
DiameterColourNodeConnectorPin
20,5MN-T1 1XP0352
D03015
30,5MB-T1 1XP0351
D03014

3.0 V6

P045 Left front tweeter speaker
WiringColour
30 LEFT FRONT DOOR
PinCableDestination
DiameterColourNodeConnectorPin
20,5MN-T1 1XP0352
D03015
30,5MB-T1 1XP0351
D03014
