I014 Sun blind control switch
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Switches › I014 Sun blind control switch
Connectors and pin-outsI014 Sun blind control switch
I014 Sun blind control switch
| Wiring | Colour |
|---|---|
| 78 CENTRE CONSOLE BRIDGE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Diameter | Colour | Node | Connector | Pin | |
| 3 | 0,35 | SV | D037 | 4 | |
| 5 | 0,35 | sz | D037 | 5 | |
| 7 | 0,35 | GR | X | H063 | 1 |
| G044 | 2 | ||||
| D037 | 1 | ||||
| I011 | 1 | ||||
| H008 | 1 | ||||
| 8 | 0,35 | NZ | X | G044 | 1 |
| I011 | 2 | ||||
| H008 | 6 | ||||
| H063 | 2 | ||||
| G037 | 1 | ||||
| D037 | 2 | ||||
| Wiring | Colour |
|---|---|
| 78 CENTRE CONSOLE BRIDGE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Diameter | Colour | Node | Connector | Pin | |
| 3 | 0,35 | SV | D037 | 4 | |
| 5 | 0,35 | sz | D037 | 5 | |
| 7 | 0,35 | GR | X | H063 | 1 |
| G044 | 2 | ||||
| D037 | 1 | ||||
| I011 | 1 | ||||
| H008 | 1 | ||||
| 8 | 0,35 | NZ | X | G044 | 1 |
| I011 | 2 | ||||
| H008 | 6 | ||||
| H063 | 2 | ||||
| G037 | 1 | ||||
| D037 | 2 | ||||
| Wiring | Colour |
|---|---|
| 78 CENTRE CONSOLE BRIDGE |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Diameter | Colour | Node | Connector | Pin | |
| 3 | 0,35 | SV | D037 | 4 | |
| 5 | 0,35 | sz | D037 | 5 | |
| 7 | 0,35 | GR | X | H063 | 1 |
| G044 | 2 | ||||
| D037 | 1 | ||||
| I011 | 1 | ||||
| H008 | 1 | ||||
| 8 | 0,35 | NZ | X | G044 | 1 |
| I011 | 2 | ||||
| H008 | 6 | ||||
| H063 | 2 | ||||
| G037 | 1 | ||||
| D037 | 2 | ||||
| Wiring | Colour |
|---|---|
| 78 CENTRE CONSOLE BRIDGE |
