Connectors and pin-outsP055 heated rearscreen
P055 HEATED REARSCREEN
P055A – Tailgate
| Wiring | Colour |
|---|---|
| See 27 TAILGATE | BIANCO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | RB | See D085 REAR/TAILGATE COUPLING | 6 | |
P055B – Tailgate
| Wiring | Colour |
|---|---|
| See 27 TAILGATE | BIANCO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | N | See D085 REAR/TAILGATE COUPLING | 12 | |
