VEHICLE TOWING AND LIFTING POINTS

TOWING POINTS

The vehicle has two threaded sockets, one at the front and one at the rear, for fitting the tow hook which is housed in the compartment in the spare wheel in the luggage compartment under the carpet.

When towing the vehicle, the laws governing towing and road traffic must be obeyed.

Thoroughly clean the threaded housing before tightening the tow hook.

Before towing, make sure that the tow hook is fully tightened.

Turn the ignition key to the ON position and then to the OFF position and DO NOT EXTRACT IT !

When the key is extracted, the steering lock is immediately engaged and it is consequently impossible to steer the wheels.

With the engine switched off, as the brake servo and the power assisted steering are not working, greater force will have to be exerted on both the pedal and the steering wheel.

VEHICLE LIFTING POINTS

To lift the vehicle using a ramp or hoist, place the ends of the arms or hoist only in the areas shown in the figure.

Before lifting the vehicle using portable lifts, lock the wheels by placing chocks in front of (behind) the front (rear) wheels.

After having raised the vehicle, support it using safety stands.
