IDENTIFICATION PLATES

VEHICLE IDENTIFICATION DATA PLATE

It is fitted to the front crossmember of the engine compartment

A. Manufacturer's name

B. Homologation number

C. Vehicle type identification code.

D. Chassis manufacturing serial number

E. Maximum authorised fully laden vehicle weight.

E. Maximum authorised fully laden vehicle weight plus trailer

G. Maximum authorised weight on the first axle (front).

H. Maximum authorised weight on the second axle (rear).

I. Engine type.

L. Body version code.

M. Part number

N. Corrected smoke absorption factor (only for Diesel engines).

PAINTWORK IDENTIFICATION PLATE

It is fitted to the front crossmember in the engine compartment (only valid for factory).

A. Bodyshell identification number

BODY MARKING

The bodyshell marking is stamped on the right turret and includes:

Vehicle type: AR 937.000

Vehicle manufacturing serial number (chassis number).

PAINTWORK IDENTIFICATION PLATE

It is fitted on the outer part of the tailgate.

1 Vehicle identification data plate

2 Plate containing bodyshell identification number (only valid for factory)

3 Bodyshell marking

4 Bodywork paint identification plate.

ENGINE MARKING POSITION

T.SPARK Engines

The engine marking is stamped on the crankcase, gearbox side, near the exhaust manifold attachment.
