Engine flywheel protection r r

Make

Fiat

Model

Panda Factory Service Manual

Year

2003–2012

Section

Crankshaft and flywheel › Engine flywheel protection r r

EngineEngine flywheel protection r r

ENGINE FLYWHEEL PROTECTION R R

Operation 1024B54 · ENGINE FLYWHEEL

1.1

Removing

1.2 8v

Removing

Op. 7055B54 UNDER-ENGINE GUARD - R R

1. Undo the fixing bolts (1a) and remove bracket (1b) and release bracket (1c).

2. Unscrew the fixing bolts (2a) and remove the engine flywheel guard (2b).

1.2 8v · 4X4

Refitting

Fit the engine flywheel guard and tighten the retaining bolts.

Fit the exhaust mounting bracket and tighten the fixing bolts.

	Fastening	Component	Ø	Value (daNm)
	Bolt	EXHAUST PIPE MOUNTS/FASTENERS	M10 X 1.25	5

	Fastening	Component	Ø	Value (daNm)
	Bolt	EXHAUST PIPE MOUNTS/FASTENERS	M8	2.5
