Alfa Romeo 156 Factory Service Manual (1997-2002)14 · Connectors and pin-outs
14 · General

I45 Seat belts warning light switch

Make
Alfa Romeo
Model
156 Factory Service Manual
Year
1997–2002
Section
Switches › I45 Seat belts warning light switch
Connectors and pin-outsI45 Seat belts warning light switch

I45 Seat belts warning light switch

Connector I45 – rear harness (black)

Connector I45, Seat belts warning light switch
Pinmm²ColourTo
1LRblue/redD20 pin 10
21.0NblackC31
