Running gearBrake allocation via PR No.
| Brake allocation via PR No. |
| The type of brake system installed in the vehicle is indicated among other things by the corresponding PR number on the vehicle data sticker. |
|
|
|
| Example of a vehicle data sticker: |
| In this example the vehicle is equipped with the following brakes: |
| t
| Arrow 1 - Rear brakes -1KQ |
| t
| Arrow 2 - Front brakes -1ZE |
| The vehicle data sticker can be found in the spare wheel well and in the service booklet. |
| t
| The following tables explain the PR numbers. These are relevant for the brake caliper/brake disc and brake pads. |
|
|
|
