86 - ELECTRICALCIRCUIT BOARD
ELECTRICAL
47
REPAIR
CIRCUIT BOARD
Service repair no - 88.20.25
Remove
1. Remove binnacle.
See Instrument Binnacle
2. Remove screw, release lower cover from circuit
board.
3. Remove 2 screws securing circuit board to
binnacle, release board.
4. Disconnect multiplug.
Refit
5. Reverse removal procedure.
